● Bi-directional control for dual brushed DC motor.
● Support motor voltage from 7V to 35V.
● Maximum current up to 80A peak (1 second), 30A continuously, each channel.
● On board MOSFETs are switched at 18 KHz for quiet operation.
● Battery low voltage indicator.
● Battery over voltage indicator.
● Thermal protection.
● Current limit protection.
● Multiple input modes: RC, Analog/PWM, Serial Simplified and Serial Packetized.
● On board push buttons for fast test and manual operation.
